ESAB 100i - Technical Specifications

100i / 200i / 300i / 400i
22 SPECIFICATIONS Manual PN: 0560956430
2.06 Specifications & Electrical Requirements
100 Amp System
100i Specifications & Design Features
Max OCV (U0) 425 vdc
Minimum Output Current 5 Amps
Max Output Current 100 Amps
Output Voltage 60 - 180 vdc
Duty Cycle Rating 100% @ 100A, 200V, (20kW),
Ambient Temperature
for Duty Cycle Rating
104F° (40°C)
Operating range 14°F to 122°F (-10°C to + 50°C)
Power Factor 0.94 @ 100 A DC Output
Cooling Coolant and Forced Air (Class F)
200 Amp System
200i Specifications & Design Features
Max OCV (U0) 425 vdc
Minimum Output Current 5 Amps
Max Output Current 200 Amps
Output Voltage 60 - 180 vdc
Duty Cycle Rating 100% @ 200A, 200V, (40kW),
Ambient Temperature
for Duty Cycle Rating
104F° (40°C)
Operating range 14°F to 122°F (-10°C to + 50°C)
Power Factor 0.94 @ 200 A DC Output
Cooling Coolant and Forced Air (Class F)
300 Amp System
300i Specifications & Design Features
Max OCV (U0) 425 vdc
Minimum Output Current 5 Amps
Max Output Current 300 Amps
Output Voltage / IEC 60 - 180 vdc / 60 - 200 vdc
Duty Cycle Rating 100% @ 300A, 200V, (60kW),
Ambient Temperature
for Duty Cycle Rating
104F° (40°C)
Operating range 14°F to 122°F (-10°C to + 50°C)
Power Factor 0.94 @ 300 A DC Output
Cooling Coolant and Forced Air (Class F)
400 Amp System
400i Specifications & Design Features
Max OCV (U0) 425 vdc
Minimum Output Current 5 Amps
Max Output Current 400 Amps
Output Voltage 60 - 200 vdc
Duty Cycle Rating 100% @ 400A, 200V, (80kW),
Ambient Temperature
for Duty Cycle Rating
104F° (40°C)
Operating range 14°F to 122°F (-10°C to + 50°C)
Power Factor 0.94 @ 400 A DC Output
Cooling Coolant and Forced Air (Class F)
