ESAB 100i - Power Supply Replacement Parts - Lower Right Side

100i / 200i / 300i / 400i
104 PARTS LISTS Manual PN: 0560956430
6.09 Power Supply Replacement Parts - Lower Right Side
Item # Qty Description Ref. Des. Catalog #
1 1 Coolant Tank Cap 8-5142
2 1 Coolant Tank 9-7306
3 1 Coolant level Sensor 9-7307
4 1 Pump, Coolant, Assembly (with motor) 9-7309
1 Pump, Coolant, Assembly (no motor) 9-7422
5 1 Motor, Pump (motor only) 9-7424
6 1 Cooling Fan(s) 9-7348
7 1 Radiator 9-7349
8 1 Flow, Switch (Not shown) FS1 9-7310
9 1 Bubble (flow) Sensor (Not shown) FL1 9-9359
10 1 Current Transducer, 300A (Not shown) HCT1 W7005324
2
3
4
5
6
7
1
Art # A-11984_AB
8
