ESAB 100i - Connect Cable and Gas Section Console Fiber Optic Cable to CCM

100i / 200i / 300i / 400i
Manual PN: 0560956430 INSTALLATION 47
3.14 Connect Cable and Gas Section Console Fiber Optic Cable to CCM
1. Remove the bottom plastic plug in the CCM at the rear of the Power Supply.
COOLANT
RETURN SUPPLY
Art # A-11991
USER INPUT
HEIGHT CONTROL
F1 - 8A SB 230 VAC F2 - 8A SB 230 VAC
CB4 - 5A 120 VAC
CB3 - 5A 24 VAC
CB2 - 5A 120 VAC
J55 - GCM
J15 - CNC
J59 - RAS
J70 - HE
J54 - TSC /COMM
USER INPUT
HEIGHT CONTROL
F1 - 8A SB 230 VAC F2 - 8A SB 230 VAC
CB4 - 5A 120 VAC
CB3 - 5A 24 VAC
CB2 - 5A 120 VAC
J55 - GCM
J15 - CNC
J59 - RAS
J70 - HE
J54 - TSC /COMM
TSC-3000 Cable
DMC-3000 Fiber
Optic Cable
Communication Cable
Gas Selection Console
Fiber Optic Cabe
