ESAB 100i - Recommended Gas Supply Hose; Leads and Cables All Amperage

100i / 200i / 300i / 400i
34 INSTALLATION Manual PN: 0560956430
3.05 Recommended Gas Supply Hose
Item # Qty Description Catalog #
1 3/8”Gray Synflex Hose. No fittings included. Catalog number per foot. 9-3616
3.06 Leads and Cables All Amperage
Green / Yellow # 4 AWG
Green / Yellow 1/0 (50 mm )
A
Green
Red
Art # A-11997_AB
#8 AWG Cable
B
C
D
F
F1
K
L
H, Q,
R,T, U
Work Cable
37
Coolant Supply Lead,
Power Supply to Arc Starter
Pilot Return, Power Supply
to Arc Starter
Negative Lead, Power Supply
to Arc Starter
Ground Cable
Ground Cable,
Remote Arc Starter
To Earth Ground
O
P, W
Fiber Optic Cable,
Power Supply to
Gas Control Module
Control Cable,
Power Supply to
Gas Control Module
Green
Red
Coolant Return Lead,
Power Supply to Arc Starter
2
G
Shielded Torch Lead
Assembly, Remote
Arc Starter to Torch
3/0 AWG Cable (95 mm
2
)
E,Y
14/7
E - Control Cable, Power Supply
to Arc Starter
Y - Control Cable to Heat Exchanger
3/0 (95 mm ) Cable
2
For use with
DFC-3000
Plasma Gas Lead,
Torch Valve to Torch
Shield Gas Lead,
Torch Valve to Torch
I
J
16 pin
S,V
S - Control Cable,
DMC-3000 to DPC-3000
V - TSC-3000 to PS
CNC Cable (37 Wire)
W - CNC Communitcation
Cable (11 Wire)
37/11
