100i / 200i / 300i / 400i
Manual PN: 0560956430 INSTALLATION 31
SECTION 3: INSTALLATION
3.01 Installation Requirements
Electric Supply
The electrical supply network, the gas and water supply system must meet local safety standards. This conformity shall
be checked by qualified personnel.
100i Power Supply
Input Power Input Current Suggested Sizes (See Note)
Voltage Freq. 3-Ph 3-Ph Fuse (Amps) Wire (AWG) Wire (mm
2
)
(Volts) (Hz) (kVA) (Amps) 3-Ph 3-Ph 3-Ph
380 50/60 21 33 40-45 #12 4
400/400 CE 50/60 21 31 40-45 #12 4
480 50/60 21 26 35-40 #12 4
200i Power Supply
Input Power Input Current Suggested Sizes (See Note)
Voltage Freq. 3-Ph 3-Ph Fuse (Amps) Wire (AWG) Wire (mm
2
)
(Volts) (Hz) (kVA) (Amps) 3-Ph 3-Ph 3-Ph
380 50/60 42 65 100 #6 16
400/400 CE 50/60 42 62 100 #6 16
480 50/60 42 52 100 #8 10
300i Power Supply
Input Power Input Current Suggested Sizes (See Note)
Voltage Freq. 3-Ph 3-Ph Fuse (Amps) Wire (AWG) Wire (mm
2
)
(Volts) (Hz) (kVA) (Amps) 3-Ph 3-Ph 3-Ph
380 50/60 63 97 150 #4 25
400/400 CE 50/60 63 93 150 #4 25
480 50/60 63 77 150 #4 25
400i Power Supply
Input Power Input Current Suggested Sizes (See Note)
Voltage Freq. 3-Ph 3-Ph Fuse (Amps) Wire (AWG) Wire (mm
2
)
(Volts) (Hz) (kVA) (Amps) 3-Ph 3-Ph 3-Ph
380 50/60 93 144 200 #1 50
400/400 CE 50/60 93 137 200 #1 50
480 50/60 93 114 175 #3 35
NOTE!
* Suggested wire size based on United States NFPA 70 National Electrical Code 2011 edition
published by the National Fire Prevention Association. Listings are from table 400.5(A)(2) for flex-
ible cord of certain types rated for 75 deg C in ambient temperatures up to 30 deg C. Using wires
of lower temperature rating or different insulation type may require larger wire size. Derate for
higher ambient.
These are suggestions only. Always refer to your local and national codes that apply to your region
for final determination of correct wire type and size.
