ESAB 100i - Appendix 3: Cooling Diagram

100i / 200i / 300i / 400i
A-10 APPENDIX Manual PN: 0560956430
APPENDIX 3: Cooling Diagram
Art # A-12268
HS1 Temp Sensor
Flow Switch
Bubble Sensor
Level Switch
HE400
Torch Coolant Supply Torch Coolant Return
Cold Plate 1
Cold Plate 2 Cold Plate 3
Radiator
Pump
Coolant tank
Filter 1
Over Flow
Supply
RAS 1000
XT-300
**FOR 400 AMP SYSTEMS
Coolant Return
Flow
Flow
ULTRA CUT XT POWER SUPPLIES 100A-400A
REV DESCRIPTION DATE APPROVED
AA ECO B2502 8-8-2013 AJR
