ESAB 100i - Power Supply Rear Panel Features

100i / 200i / 300i / 400i
Manual PN: 0560956430 SPECIFICATIONS 25
2.08 Power Supply Rear Panel Features
USER INPUT
HEIGHT CONTROL
F1 - 8A SB 230 VAC F2 - 8A SB 230 VAC
CB4 - 5A 120 VAC
CB3 - 5A 24 VAC
CB2 - 5A 120 VAC
J55 - GCM
J15 - CNC
J59 - RAS
J70 - HE
J54 - TSC /COMM
Art # A-11842_AB
AC Power Lamp
Negative Return
Coolant Filter
C.C.M.
Circuit Breakers
Input Power
Ports
Arc Starter Connector
Coolant Return
Coolant Supply
H.E. Connector
Customer
Optional
Ports
Pilot Lead
Work Lead
Fuse
CNC Connector
GCM Connector
TSC/Comm
