100i / 200i / 300i / 400i
24 SPECIFICATIONS Manual PN: 0560956430
NOTE!
* Suggested wire size based on United States NFPA 70 National Electrical Code 2011 edition
published by the National Fire Prevention Association. Listings are from table 400.5(A)(2) for
flexible cord of certain types rated for 75 deg C in ambient temperatures up to 30 deg C.
Using wires of lower temperature rating or different insulation type may require larger wire
size. De-rate for higher ambient. These are suggestions only. Always refer to your local and
national codes that apply to your region for final determination of correct wire type and size.
2.07 Power Supply Dimensions
Art # A-11487_AB
35.97 inch
914 mm
27.6 inch
701 mm
47.77 inch
1213 mm
100A 420 lb / 190 kg
200A 465 lb / 211 kg
300A 560 lb / 254 kg
400A 580 lb / 263 kg
