ESAB 100i - Page 23

100i / 200i / 300i / 400i
Manual PN: 0560956430 SPECIFICATIONS 23
100i Power Supply
Input Power Input Current Suggested Sizes (See Note)
Voltage Freq. 3-Ph 3-Ph Fuse (Amps) Wire (AWG) Wire (mm
2
)
(Volts) (Hz) (kVA) (Amps) 3-Ph 3-Ph 3-Ph
380 50/60 21 33 40-45 #12 4
400/400 CE 50/60 21 31 40-45 #12 4
480 50/60 21 26 35-40 #12 4
200i Power Supply
Input Power Input Current Suggested Sizes (See Note)
Voltage Freq. 3-Ph 3-Ph Fuse (Amps) Wire (AWG) Wire (mm
2
)
(Volts) (Hz) (kVA) (Amps) 3-Ph 3-Ph 3-Ph
380 50/60 42 65 100 #6 16
400/400 CE 50/60 42 62 100 #6 16
480 50/60 42 52 100 #8 10
300i Power Supply
Input Power Input Current Suggested Sizes (See Note)
Voltage Freq. 3-Ph 3-Ph Fuse (Amps) Wire (AWG) Wire (mm
2
)
(Volts) (Hz) (kVA) (Amps) 3-Ph 3-Ph 3-Ph
380 50/60 63 97 150 #4 25
400/400 CE 50/60 63 93 150 #4 25
480 50/60 63 77 150 #4 25
400i Power Supply
Input Power Input Current Suggested Sizes (See Note)
Voltage Freq. 3-Ph 3-Ph Fuse (Amps) Wire (AWG) Wire (mm
2
)
(Volts) (Hz) (kVA) (Amps) 3-Ph 3-Ph 3-Ph
380 50/60 93 144 200 #1 50
400/400 CE 50/60 93 137 200 #1 50
480 50/60 93 114 175 #3 35
