TORCH DATA 100i-400i 222 Manual 0560956430
Torch Head O-Ring
Torch Head
Art # A-07202_AB
0.063 - 0.083"
(1.6 - 2.1 mm)
Protrusion
Installing Assembled Cartridge Onto Torch Head
3. Slide the ohmic clip over the shield cup if using ohmic torch height control sensing.
NOTE
Ohmic height sensing is not recommended with water shield. Water on the plate interferes
electrically with the ohmic sensing circuit.
Ohmic Clip
Art # A-03393_AB
4. Connect the wire lead from the height finder to the ohmic clip.
To Next Page
