100i / 200i / 300i / 400i
Manual PN: 0560956430 OPERATION 83
CCM Status Code
Group 2 -- Plasma Power Supply
210
Work Current Too
High
Work lead current detected greater than 16% above process setting. Possible defec-
tive HCT1 Work lead current sensor or Relay PCB; Defective CCM.
211
Work Current Too
Low
Work current detected more than 16% below process setting. Possible defective
HCT1 Work lead current sensor or Relay PCB; Possible defective pilot PCB (shorted
IGBT);
212
Inverter 1A Output
Current Low
Plasma work current low during cutting and attributed to Inverter Module 1 Sec-
tion A output low; Inverter output disconnected; Possible defective ribbon cable; If
problem persists replace Inverter Module 1
213
Inverter 1B Output
Current Low
Plasma work current low during cutting and attributed to Inverter Module 1 Sec-
tion B output low; Inverter output disconnected; Possible defective ribbon cable; If
problem persists replace Inverter Module 1
214
Inverter 2A Output
Current Low
Plasma work current low during cutting and attributed to Inverter Module 2 Section
A output low; Inverter output disconnected; Possible defective ribbon cable; If
problem persists replace Inverter Module 2
215
Inverter 2B Output
Current Low
Plasma work current low during cutting and attributed to Inverter Module 2 Section
B output low; Inverter output disconnected; Possible defective ribbon cable; If
problem persists replace Inverter Module 2
216
Inverter 3A Output
Current Low
Plasma work current low during cutting and attributed to Inverter Module 3 Section
A output low; Inverter output disconnected; Possible defective ribbon cable; If
problem persists replace Inverter Module 3
217
Inverter 3B Output
Current Low
Plasma work current low during cutting and attributed to Inverter Module 3 Section
B output low; Inverter output disconnected; Possible defective ribbon cable; If
problem persists replace Inverter Module 2
218
Inverter 1A Output
Current High
Plasma work current high during cutting and attributed to Inverter Module 1 Section
A output high; If problem persists replace Inverter Module 1
219
Inverter 1B Output
Current High
Plasma work current high during cutting and attributed to Inverter Module 1 Section
B output high; If problem persists replace Inverter Module 1
220
Inverter 2A Output
Current High
Plasma work current high during cutting and attributed to Inverter Module 2 Section
A output high; If problem persists replace Inverter Module 2
221
Inverter 2B Output
Current High
Plasma work current high during cutting and attributed to Inverter Module 2 Section
B output high; If problem persists replace Inverter Module 2
222
Inverter 3A Output
Current High
Plasma work current high during cutting and attributed to Inverter Module 3 Section
A output high; If problem persists replace Inverter Module 3
223
Inverter 3B Output
Current High
Plasma work current high during cutting and attributed to Inverter Module 3 Section
B output high; If problem persists replace Inverter Module 3
224 Inverter 1 Not Found
Inverter Module 1 Section A required for Piloting; Bad ribbon cable connection to
CCM J31 to Inverter Module 1 Section A.
225
Inverter 1A Incompat-
ible Revision
Unsupported Inverter Revision; Ribbon cable CCM J31 to Inverter Module 1 Section
A damaged; CCM code version incompatible with Inverter revision or model
226
Inverter 1B Incompat-
ible Revision
Unsupported Inverter Revision; Ribbon cable CCM J32 to Inverter Module 1 Section
B damaged ; CCM code version incompatible with Inverter revision or model
227
Inverter 2A Incompat-
ible Revision
Unsupported Inverter Revision; Ribbon cable CCM J33 to Inverter Module 2 Section
A damaged; CCM code version incompatible with Inverter revision or model
228
Inverter 2B Incompat-
ible Revision
Unsupported Inverter Revision; Ribbon cable CCM J34 to Inverter Module 2 Section
B damaged; CCM code version incompatible with Inverter revision or model
229
Inverter 3A Incompat-
ible Revision
Unsupported Inverter Revision; Ribbon cable CCM J35 to Inverter Module 3 Section
A damaged; CCM code version incompatible with Inverter revision or model
