100i / 200i / 300i / 400i
90 OPERATION Manual PN: 0560956430
Gas Selection Console Status Code Key
Group 1 - Gas Selection Console
Code Message Cause/Remedy
1-1 Plasma Disabled Enable Plasma; Defective Gas Selection Console Power Supply (E-Stop relay)
1-2 24 VDC fault Check /replace Gas Selection Console power supply fuse (F2); Replace Gas Selection
Console Power Supply; Replace Gas Selection Console control PCB
1-3 5 VDC fault Check /replace Gas Selection Console power supply; Replace Gas Selection Console
control PCB
1-4 No gas process selected Select and send process from or CNC;
1-5 Gas Selection Console is
locked
Process loading, wait until finished
1-6 Gas not Purged Gas Control Unit fault prevented purge from occuring, see Gas Control Unit fault status
Group 2 - Gas Control Unit Communication Port *
2-1 Gas Control Unit Ac-
knowledge error
Check Gas Selection Console to Gas Control Unit fiber optic cable and connections; Dirty
or defective fiber-optic;Gas Control Unit power supply, fuse or Control PCB. Gas Selec-
tion Console Control PCB
2-2 Gas Control Unit Bus off
error
Check Gas Selection Console to Gas Control Unit fiber optic cable and connections; Dirty
or defective fiber-optic;Gas Control Unit power supply, fuse or Control PCB. Gas Selec-
tion Console Control PCB.
2-3 Reserved No information available; Contact customer service
Group 3 - CCM Communication Port *
3-1 CCM Acknowledge error Check Gas Selection Console to CCM fiber optic cable and connections; Dirty or defec-
tive fiber-optic; Replace Gas Selection Console Control PCB; Replace CCM.
3-2 CCM Bus off error Check Gas Selection Console to CCM fiber optic cable and connections; Dirty or defec-
tive fiber-optic; Replace Gas Selection Console Control PCB; Replace CCM.
3-3 Reserved No information available; Contact customer service
Group 4 - Gas Controller Status and Protocal Errors
4-1 CCM Connection loss Loss of communication with either Gas Control Unit or Gas Selection Console; check for
dirty or defective fiber optic to either Gas Control Unit or CCM; See Gas Control Unit and
CCM status codes
4-2 CCM Timeout Loss of communication with either Gas Control Unit or Gas Selection Console, check for
dirty or defective fiber-optic to either Gas Control Unit or CCM. See Gas Control Unit and
CCM status codes.
