EtherWAN EW50 User Manual

EW50 Industrial LTE Cellular Gateway
114
all client hosts in these both subnets can communicate with each other.
Parameter Setup Example
For Network-A at HQ
The following tables list the parameter configuration as an example for the "My Certificate" function
used in the user authentication of IPsec VPN tunnel establishing, as shown in the above diagram.
The configuration example must be combined with the ones in following two sections to complete
the whole user scenario.
Use default value for parameters that are not mentioned in the tables.
Configuration Path
[My Certificate]-[Root CA Certificate Configuration]
Name
HQRootCA
Key
Key Type: RSA Key Length: 1024-bits
Subject Name
Country(C): TW State(ST): Taiwan Location(L): Taipei
Organization(O): EWANHQ Organization Unit(OU): HQRD
Common Name(CN): HQRootCA E-mail: hqrootca@etherwan.com.tw
Configuration Path
[My Certificate]-[Local Certificate Configuration]
Name
HQCRT Self-signed: ■
Key
Key Type: RSA Key Length: 1024-bits
Subject Name
Country(C): TW State(ST): Taiwan Location(L): Taipei
Organization(O): EWANHQ Organization Unit(OU): HQRD
Common Name(CN): HQCRT E-mail: hqcrt@etherwan.com.tw
Configuration Path
[IPSec]-[Configuration]
IPSec
■ Enable
Configuration Path
[IPSec]-[Tunnel Configuration]
Tunnel
■ Enable
Tunnel Name
s2s-101
Interface
WAN 1
Tunnel Scenario
Site to Site
Operation Mode
Always on
Configuration Path
[IPSec]-[Local & Remote Configuration]
Local Subnet
10.0.76.0
Local Netmask
255.255.255.0
Full Tunnel
Disable
Remote Subnet
10.0.75.0
Remote Netmask
255.255.255.0
Remote Gateway
118.18.81.33
