OpenVPN Client Configuration
Item
Value setting
Description
OpenVPN Client
Name
Required setting
The OpenVPN Client Name will be used to identify the client in the tunnel list.
Value Range: 1 ~ 32 characters.
Interface
1. Required setting
2. By default WAN-1 is
selected.
Define the physical interface to be used for this OpenVPN Client tunnel.
Protocol
1. Required setting
2. By default TCP is
selected.
Define the Protocol for the OpenVPN Client.
 Select TCP
-> OpenVPN will use TCP, and Port will be set to 443.
 Select UDP
-> OpenVPN will use UDP, and Port will be set to 1194.
Port
1. Required setting
2. By default 443 is
set.
Specify the Port for the OpenVPN Client to use.
Value Range: 1 ~ 65535.
Tunnel Scenario
1. Required setting
2. By default TUN is
selected.
Specify the type of Tunnel Scenario for the OpenVPN Client to use. It can be
TUN for TUN tunnel scenario, or TAP for TAP tunnel scenario.
Remote IP/FQDN
Required setting
Specify the Remote IP/FQDN of the peer OpenVPN Server for this OpenVPN
Client tunnel. Enter the IP address or FQDN.
Remote Subnet
Required setting
Specify Remote Subnet of the peer OpenVPN Server for this OpenVPN Client
tunnel.
Fill in the remote subnet address and remote subnet mask.
Redirect Internet
Traffic
1. Optional setting.
2. Unchecked by
default
Check the Enable box to activate the Redirect Internet Traffic function.
NAT
1. Optional setting.
2. Unchecked by
default
Check the Enable box to activate the NAT function.
Authorization Mode
1. Required setting
2. By default TLS is
selected.
Specify the authorization mode for the OpenVPN Server.
 TLS
->The OpenVPN will use TLS authorization mode, and the following items CA
Cert., Client Cert. and Client Key will be displayed.
CA Cert. can be selected in Trusted CA Certificate List. Refer to Object Definition
> Certificate > Trusted Certificate.
Client Cert. can be selected in Local Certificate List. Refer to Object Definition >
Certificate > My Certificate.
Client Key can be selected in Trusted Client key List. Refer to Object Definition >
Certificate > Trusted Certificate.
 Static Key
-> OpenVPN will use static key authorization mode, and the following items
Local Endpoint IP Address, Remote Endpoint IP Address and Static Key will be
displayed.
Local Endpoint IP
Address
Required setting
Specify the virtual Local Endpoint IP Address of this OpenVPN gateway.
Value Range: The IP format is 10.8.0.x, the range of x is 1~254.
Note: Local Endpoint IP Address will be available only when Static Key is chosen
in Authorization Mode.
Remote Endpoint IP
Address
Required setting
Specify the virtual Remote Endpoint IP Address of the peer OpenVPN gateway.
Value Range: The IP format is 10.8.0.x, the range of x is 1~254.
Note: Remote Endpoint IP Address will be available only when Static Key is
chosen in Authorization Mode.
