EW50 Industrial LTE Cellular Gateway
209
are VLAN-1 to VLAN-2. VLAN-1 to WAN.
Select Any to filter packets coming into the router from any interfaces.
Please note that two identical interfaces are not accepted by the router. e.g.,
VLAN-1 to VLAN-1.
1. Required setting
2. By default Any is
selected
Define the selected interface to be the packet-leaving interface of the router. If
the packets to be filtered are entering from LAN to WAN then select WAN for
this field. If VLAN-1 to WAN then select WAN for this field. Other examples are
VLAN-1 to VLAN-2. VLAN-1 to WAN.
Select Any to filter packets leaving the router from any interfaces.
Please note that two identical interfaces are not accepted by the router. e.g.,
VLAN-1 to VLAN-1.
1. Required setting
2. By default Any is
selected
This field is to specify the Source IP address.
Select Any to filter packets coming from any IP addresses.
Select Specific IP Address to filter packets coming from an IP address.
Select IP Range to filter packets coming from a specified range of IP address.
Select IP Address-based Group to filter packets coming from a pre-defined
group. Note: group must be pre-defined before this option becomes available.
Refer to Object Definition > Grouping > Host grouping. You may also access to
create a group by the Add Rule shortcut button.
1. Required setting
2. By default Any is
selected
This field is to specify the Destination IP address.
Select Any to filter packets that are entering to any IP addresses.
Select Specific IP Address to filter packets entering to an IP address entered in
this field.
Select IP Range to filter packets entering to a specified range of IP address
entered in this field.
Select IP Address-based Group to filter packets entering to a pre-defined group
selected. Note: group must be pre-defined before this selection become
available. Refer to Object Definition > Grouping > Host grouping. You may also
access to create a group by the Add Rule shortcut button. Setting done through
the Add Rule button will also appear in the Host grouping setting screen.
1. Required setting
2. By default Any is
selected
This field is to specify the Source MAC address.
Select Any to filter packets coming from any MAC addresses.
Select Specific MAC Address to filter packets coming from a MAC address.
Select MAC Address-based Group to filter packets coming from a pre-defined
group selected. Note: group must be pre-defined before this selection become
available. Refer to Object Definition > Grouping > Host grouping. You may also
access to create a group by the Add Rule shortcut button.
1. Required setting
2. By default Any(0) is
selected
For Protocol, select Any to filter any protocol packets
For Source Port, select a predefined port dropdown box when Well-known
Service is selected, otherwise select User-defined Service and specify a port
range.
For Destination Port, select a predefined port dropdown box when Well-known
Service is selected, otherwise select User-defined Service and specify a port
range.
Value Range: 1 ~ 65535 for Source Port, Destination Port.
For Protocol, select ICMPv4 to filter ICMPv4 packets
