EW50 Industrial LTE Cellular Gateway
213
Create/Edit MAC Control Rules
The gateway supports up to a maximum of 20 filter rule sets. Ensure that the MAC Control is enabled before
creating control rules.
When Add button is applied, Filter Rule Configuration screen will appear.
MAC Control Rule Configuration
Item
Value setting
Description
Rule Name
1. String format, any text
2. Required setting
Enter a MAC Control rule name.
MAC Address
(Use: to
Compose)
1. MAC Address string
Format
2. Required setting
Specify the Source MAC Address to filter rule.
Time Schedule
Required setting
Apply Time Schedule to this rule; otherwise leave it as (0) Always.
If the dropdown list is empty, ensure Time Schedule is pre-configured. Refer to
Object Definition > Scheduling > Configuration tab
Enable
Unchecked by default
Click Enable box to activate this rule, and then save the settings.
Save
N/A
Click Save to save the settings
Undo
N/A
Click Undo to cancel the settings
Back
N/A
Click Back to return to the MAC Control Configuration page.
