EW50 Industrial LTE Cellular Gateway
303
names will be 3G/4G-1 and 3G/4G-2.
Card
Information
N/A
Displays the vendor’s 3G/4G modem model name.
Link Status
N/A
Displays the 3G/4G connection status. The status can be Connecting, Connected,
Disconnecting, and Disconnected.
Signal
Strength
N/A
Displays the 3G/4G wireless signal level.
Network
Name
N/A
Displays the name of the service network carrier.
Refresh
N/A
Click the Refresh button to renew the information.
Action
N/A
Detail Button: when pressed, windows with detailed information will appear. They are
Modem Information, SIM Status, and Service Information. Refer to next page for
more.
When the Detail button is pressed, 3G/4G modem information windows such as Modem Information, SIM
Status, Service Information, and Signal Strength / Quality will appear.
Interface Traffic Statistics
Interface Traffic Statistics screen displays the Interface’s total transmitted packets.
Interface Traffic Statistics
Item
Value setting
Description
ID
N/A
Displays corresponding WAN interface WAN IDs.
Interface
N/A
Displays the type of WAN physical interface.
Depending on the model, it can be Ethernet, 3G/4G, etc.
Received Packets
(Mb)
N/A
Displays the downstream packets (Mb). It is reset when the device is rebooted.
Transmitted Packets
(Mb)
N/A
Displays the upstream packets (Mb). It is reset when the device is rebooted.
