Machine description
PHOENIX 301; 351; 421; 521 EXPERT forceArc
16 Item No.: 099-004833-EWM01
4 Machine description
4.1 PHOENIX 301; 351; 421; 521 EXPERT forceArc
4.1.1 Front view
The maximum possible machine configuration is given in the text description.
If necessary, the optional connection may need to be retrofitted (see "Accessories" chapter).
Figure 4-1
