5.2.10 MIG/MAG Powercontrol program torch
The control leads for the torches described in this chapter are fitted with a 19-pole connection
socket.
5.2.10.1 Powercontrol program torch with one rocker (standard function, factory setting)
Retrieving w
elding programs and program sequences (program function)
Changeover switch in WF unit to "Program" (see "Internal operating elements" chapter)
Operating elements Functions
1 torch trigger Welding On/Off
1 rocker Retrieve 10 welding programs (0 to 9)
8
7 segment display Display the relevant program number
Program P
A0
: Setting on the wire feed unit.
Program P
A1
- P
A9
: Setting, e.g. on M3.10/M3.11 (see MIG/MAG program sequence "Program steps
mode") or on the PHOENIX R40 remote control.
Infinitely adjustable setting of welding performance (Up/Down function)
Changeover switch in WF unit to "Up / Down" (see "Internal operating elements" chapter)
Operating elements Functions
1 torch trigger Welding On/Off
1 rocker Infinitely adjustable operating point setting (one-dial operation / Synergic)
8
7 segment display Display 0 to 9
Infinite adjustment of wire speed from 1% to 100% of the wire speed set on the wire feed unit.
The arc length is corrected on the wire feed unit.
5.2.10.2 Up / Down torch with two rockers (s
ta
ndard function, factory setting)
Infinitely adjustable setting of welding performance (Up/Down function)
Changeover switch in WF unit to "Up / Down" (see "Internal operating elements" chapter)
Operating elements Functions
1 torch trigger Welding On/Off
1st rocker Infinitely adjustable operating point setting (one-dial operation / Synergic)
2nd rocker Infinitely adjustable arc length correction setting
1
st
rocker: Infinite adjustment of wire speed from 1% to 100% of the wire speed set on the wire
feed unit.
2
nd
rocker: Infinite adjustment (absolute) arc length correction from (± 10V), regardless of the
setting on the wire feed unit.
Calling up welding programs or program sequences
Changeover switch in WF unit to "Program" (see "Internal operating elements" chapter)
Operating elements Functions
1 torch trigger Welding On/Off
1st rocker Retrieve 10 welding programs (0 to 9)
2nd rocker No function
Program 0: Setting on the wire feed control.
Program 1 - 9: Setting on welding machine control M3.10 / M3.11 or on remote control PHOENIX
R40, for example.
