Functional characteristics
Advanced functions on the wire feed unit control
90 Item No.: 099-004833-EWM01
5.10 Advanced functions on the wire feed unit control
5.10.1 Special parameter, “M3.70/M3.71”
The special parameters cannot be viewed directly since they are normally only set and stored once. The
machine control offers the following special functions:
5.10.1.1 Special parameters list
Function
Setting op
tions Ex works
P1 Ramp time for wire inching 0 = normal inching
(10 sec ramp time)
1 = fast inching
(3 sec ramp time)
1
P2 Program “0”, block 0 = P0 enabled
1 = P0 blocked
0
P3 Powercontrol torch display mode 0 = normal display
1 = alternating display
0
P4 Program limit Program 2 to max. 15 15
P5 Special cycle in the special
latched and non-latched
operating modes
0 = normal (previous) non-latched/latched
1 = DV3 cycle for non-latched/latched
0
P6 Release of special JOBs SP1–
SP3 (effective with M3.70 only)
0 = no activation
1 = activation of SP1–3
0
P7 Correction operation, threshold
value setting
0 = correction operation switched off
1 = correction operation on
The control signals that the correction
operation is on by flashing the LED “main
program (PA)”
0
P8 Program switching with standard
torch
0 = normal (previous) latched, special latched
1 = special latched
2 = specific latched special (N cycle)
(for PROGRESS and EXPERT series only)
0
P9 Lat. or lat. sp. tapping start 0 = normal (previous) latched
1 = latched tapping start possible
0
P10 Single or DUAL WF mode 0 = single WF
1 = DUAL mode (WF unit 1, master)
2 = DUAL mode (WF unit 2, slave)
(for PROGRESS and EXPERT series only)
0
P11 Special latched tapping time 0 = Tapping switched off
1 = 300ms
2 = 600ms
1
Swi Software key switch 0 = system complete
1 = system not complete
(key switch realised in software for PHOENIX
BASIC models)
1
