Functional characteristics
MIG/MAG welding
64 Item No.: 099-004833-EWM01
5.2.8.3 MIG/MAG overview of parameters for M3.1x
Different welding tasks or positions on a workpiece demand various welding outputs (operating points) or
welding programs.
For each program, the
• Wire speed
• Correction of the arc length and the
• Dynamics / choke effect
can be set separately.
15 different programs (PROG 1 to PROG 15) can be defined. It is possible to switch between these
programs during the welding process.
Display Meaning/explanation Setting range
act.Prg.: X Active main program A
0 to 15
P0 U2 :+0.0 V Arc length correction (offset WF unit)
-9.9 V to +9.9 V
P1 15 UK :+2.0 V Restriction of the setting range for the voltage
correction in program mode
0.0 V to +9.9 V
P1 15 DK : 20% Restriction of the correction range for wire correction
(for more details, see chapter on special parameters,
"DRIVE 4 P wire feed units")
0% to 30%
P1 DV2 :+2.0 m/m Wire speed
0.1 m/min to 20.0 m/min
P1 U2 :+0.0 V Arc length correction
-9.9 V to +9.9 V
P1 DYN2: + 0 Dynamics / choke effect
-40% to +40%
| | |
P2 to P14 P2 to P14
P2 to P14
| | |
P15 DV2 :+2.0m/m Wire speed
0.1 m/min to 20.0 m/min
P15 U2 :+0.0 V Arc length correction
-9.9 V to +9.9 V
P15 DYN2: + 0 Dynamics / choke effect
-40% to +40%
5.2.9 Standard MIG/MAG torch
The torch button on the MIG welding torch is normally used for starting and stopping the welding process.
Several additional functions are possible using the Powercontrol or Up/Down torch.
Operating elements Functions
1 torch trigger Welding On/Off
Special latched: "tapping" (press briefly and release) can be used to
switch between the main program P
A
and reduced main program P
B
.
