Machine description
PHOENIX DRIVE 4L; PHOENIX EXPERT DRIVE 4L
Item No.: 099-004833-EWM01 21
Item Symbol Description 0
1 Slide latch, lock for the protective cap
2 Cover for wire delivery unit and operating elements
3 Carrying handle with integrated lifting lug
4 Wire spool casing
5 Operating elements (see chapter Function specification)
6 Spool holder
7 Wire delivery unit
8
Euro-central connector (welding torch connection)
Welding current, shielding gas and torch trigger included
9 Label "Wire feed parts subject to wear"
10 Control / Operating elements (see chapter Function specification)
11
19-pole connection socket (analogue)
For connecting analogue accessory components (remote control, welding torch control
lead, intermediate drive, etc.)
12
7-pole connection socket (digital)
For connecting digital accessory components (remote control, welding torch control
lead, etc.)
13 Rapid-action closure coupling, blue (coolant supply)
14 Rapid-action closure coupling, red (coolant return)
