Machine description
PHOENIX DRIVE 4; PHOENIX EXPERT DRIVE 4
Item No.: 099-004833-EWM01 25
Item Symbol Description 0
1 Operating elements (see chapter Function specification)
2 Wire delivery unit
3
7-pole connection socket (digital)
• Control lead for wire feed unit
4
Connecting nipple G¼, shielding gas connection
5 Spool holder
6 Rapid-action closure coupling, blue (coolant supply)
7
Connector plug, welding current "+"
Welding current connection on wire feed unit
8 Rapid-action closure coupling, red (coolant return)
