EXFO MAX-890 - MAX-880 Model

Physical Interfaces and LEDs
12 MAX-800 Series
MAX-880 Model
MAX-880 Model
SFP+ P2
1
1. Laser radiation emitted from this port when LASER LED is on.
SFP+ P1
1
RJ45 P1 RJ48C
BANTAM
BNC TX/RX2
BNC RX
DUPLEX
LINK/ACT
LINK/RX LASER
LINK/RX
LASER
