Physical Interfaces and LEDs
MaxTester 13
MAX-890 and MAX-890Q Models
MAX-890 and MAX-890Q Models
The MAX-890Q model provides twice the amount of ports and capabilities
than the MAX-890. The MAX-890Q is divided into two parts labelled A and B
respectively.
1. Laser radiation emitted from this port when LASER LED is on.
Port A2
1
Port A1
1
Part A
Part B
Port B2
1
Port B1
1
