Graphical User Interface Overview
22 MAX-800 Series
Global Indicator
Global Indicator
The global indicator area displays the global pass/fail verdict, global alarm,
and the test duration.
The global indicator area can be maximized for distant viewing. Tap
anywhere within the global indicator area to display a maximized view. Tap
again to exit the maximized view.
Global
Alarm
Test T i me r
Global indicator area
History
Current
Timer
Global
Verdict
