Graphical User Interface Overview
MaxTester 23
Global Indicator
Global Verdict
Reports the global test verdict status when supported by the test
application and enabled (when applicable).
Global Alarm
Indicates the current and history alarm/error status of the test.
Verdict Description
PASS PASS is displayed with a green background when all result values meet the configured threshold
criteria.
FAIL FAIL is displayed with a red background when any result value does not meet the configured
threshold criteria or when a specific alarm is detected (refer to each test application for additional
information).
“--” “--” is displayed with a gray background when at least one of the following conditions is met:
- Pass/Fail verdict is not enabled
- there is no defined criterion
- the test has not run yet.
Background
color
Alarm/
Error
Text displayed Description
Gray Current -- No test result available.
History
Green Current No Alarm No alarm/error has occurred in the last second.
History No alarm/error has occurred during the test.
Red Current Alarms or the name of the alarm. An alarm/error occurred in the last second.
History
Amber History No current alarm/error but at least one
alarm/error has occurred during the test.
