Port Availability
Port Availability
860/860G/880
The following table shows the list of available ports as well as a description
and signals supported for each model.
Connector Labelled Description and supported signal(s)
Model
860 860G 880
Bantam BANTAM
TX/RX2
RX
TX and RX: DS1/1.5M, E1/2M
RX2: DS1/1.5M
--X
Clock IN/OUT: DS1/1.5M, E1/2M, 2 MHz
BNC BNC
TX/RX2
TX: E1/2M, E3/34M, DS3/45M, STS-1e/STM-0e/52M,
E4/140M, STS-3e/STM-1e/155M
RX2: DS3
--X
Clock OUT: DS1/1.5M, E1/2M, 2MHz
BNC
RX
E1/2M, E3/34M, DS3/45M, STS-1e/STM-0e/52M, E4/140M,
STS-3e/STM-1e/155M
--X
Clock IN: DS1/1.5M, E1/2M, 2MHz, 1 PPS
BNC
EXT CLK
Clock IN: DS1/1.5M, E1/2M, 2MHz, 1 PPS - - X
RJ45 RJ45 P1 Ethernet 10/100/1000 Mbit/s electrical X X X
RJ48C RJ48C DS1/1.5M, E1/2M - - X
Clock IN/OUT: DS1/1.5M, E1/2M, 2MHz
SFP/SFP+ SFP+ P1
or
SFP+ P2
Ethernet 100 Mbit/s, 1000 Mbit/s optical X X X
Ethernet 10 Gbit/s LAN/WAN optical - X X
OC-1/STM-0, OC-3/STM-1, OC-12/STM-4, OC-48/STM-16,
OC-192/STM-64
a
OTU1, OTU2
a. Port SFP+ P2 is used with OC-192/STM-64 in Decoupled (TX≠RX) mode.
--X
SFP+ P2 Ethernet 10/100/1000 Mbit/s electrical (using active
copper SFP)
XXX
