Test Setup - Test Configurator, Timer, and System
196 MAX-800 Series
Traces (OTN)
SAPI (Source Access Point Identifier) corresponds to the TTI bytes 0
to 15. A maximum of 16 characters is allowed. NULL (all 0’s)
characters are automatically appended to the message for bytes that
are not defined. The expected SAPI message is available when the
SAPI OTU/ODU-TIM check box is selected.
DAPI (Destination Access point Identifier) corresponds to the TTI bytes
16 to 31. A maximum of 16 characters is allowed. NULL (all 0’s)
characters are automatically appended to the message for bytes that
are not defined. The expected DAPI message is available when the
DAPI OTU/ODU-TIM check box is selected.
TTI Traces Default Message
a
a. The default message contains a NULL (all 0’s) character preceding it. NULL (all 0’s)
characters are automatically appended to the message for bytes that are not
defined.
SM EXFO OTU SAPI
PM EXFO ODU SAPI
TCM EXFO TCMi SAPI
TTI Traces Default Message
a
a. The default message contains a NULL (all 0’s) character preceding it. NULL (all 0’s)
characters are automatically appended to the message for bytes that are not
defined.
SM EXFO OTU DAPI
PM EXFO ODU DAPI
TCM EXFO TCMi DAPI
