Test Results
MaxTester 287
Summary (Cable Test)
Delay Skew (ns) indicates the delay skew value for the pair having the
worst delay skew. The Pass/Fail verdict is also displayed when enabled.
The Delay Skew result is only available for 1000 Base-T interface when
the link is up.
Length (m/ft) indicates the length for the pair having the worst cable
length value. The Pass/Fail verdict is also displayed when enabled.
Pairs
Note: When no value is available, “--” is displayed.
Pair indicates the pair number.
Pins indicates the pair’s pin numbers and color of each wire
corresponding to the selected wiring standard.
W-BL White-Blue
BL Blue
W-O White-Orange
O Orange
W-G White-Green
G Green
W-BR White-Brown
BR Brown
