Test Results
306 MAX-800 Series
Traffic - Flow Control
Pause Injection
Note: Pause injection is only available for Traffic Gen & Mon test application.
Packet Pause Time: Enter the pause time value to be transmitted in
Quanta or Microsecond (default is 100 Quanta).
Note: When entering a value in μs it will be rounded to the closest multiple of
0.0512 μs for 10 Mbit/s, 5.12 μs for 100 Mbit/s, 0.512μs for 1000 Mbit/s, 0.0512
μs for 10 Gbit/s, and 0.00512 μs for 100 Gbit/s.
Inject button allows generating the defined packet pause time.
Destination MAC Address check box, when selected (cleared by
default), enables and allows setting the destination MAC address. The
default destination MAC address is the control protocol multicast
address: 01:80:C2:00:00:01.
Interface
Range
Quanta μs
10 Mbit/s 0 to 65535 0 to 3355392
100 Mbit/s 0 to 65535 0 to 335539.2
1000 Mbit/s 0 to 65535 0 to 33553.92
10 Gbit/s 0 to 65535 0 to 3355.392
100 Gbit/s 0 to 65535 0 to 335.5392
