Test Setup - Test Applications
MaxTester 45
RFC 2544
 Typical RFC 2544 testapplications:
 Supported Interfaces/Rates: 10M to 10G LAN/WAN and 100G . Dual Port
topology is only available for rates up to 10G WAN.
Network
under test
Testing Unit Loopback Unit
EXFO Unit EXFO Unit
Network
under test
Testing Unit Remote Unit
EXFO Unit EXFO Unit
Network
under test
Testing Unit
EXFO Unit
