EXFO MAX-890 - Signal Auto-Detect

Test Setup - Test Configurator, Timer, and System
MaxTester 69
Modify Structure Button
 OTN Multiplexing - Config Mux button, available with OTN BERT,
indicates the OTN test mapping.
 SONET/SDH Multiplexing - Config Mux button allows the selection of
SONET/SDH multiplexing. Only available with SONET/SDH BERT test
application.
Interface/Rate OTN Multiplexing
OTU1 [2.666 Gbit/s] ODU1
OTU2 [10.709 Gbit/s] ODU2
Interface/Rate SONET/SDH Multiplexing
OC-192 STS-192c, STS-48c, STS-12c, STS-3c, STS-1, STS-1/VT2,
STS-1/VT1.5
STM-64 AU-4-64c, AU-4-16c, AU-4-4c, AU-4, AU-4/TU-3, AU-4/TU-12,
AU-4/TU-11, AU-3, AU-3/TU-12, AU-3/TU-11
OC-48 STS-48c, STS-12c, STS-3c, STS-1, STS-1/VT2, STS-1/VT1.5
STM-16 AU-4-16c, AU-4-4c, AU-4, AU-4/TU-3, AU-4/TU-12, AU-4/TU-11,
AU-3, AU-3/TU-12, AU-3/TU-11
OC-12 STS-12c, STS-3c, STS-1, STS-1/VT2, STS-1/VT1.5
STM-4 AU-4-4c, AU-4, AU-4/TU-3, AU-4/TU-12, AU-4/TU-11, AU-3,
AU-3/TU-12, AU-3/TU-11
OC-3 STS-3c, STS-1, STS-1/VT2, STS-1/VT1.5
STM-1 AU-4, AU-4/TU-3, AU-4/TU-12, AU-4/TU-11,
AU-3, AU-3/TU-12,
AU-3/TU-11
OC-1 STS-1, STS-1/VT2, STS-1/VT1.5
STS-3e STS-3c, STS-1, STS-1/VT2, STS-1/VT1.5
STS-1e STS-1, STS-1/VT2, STS-1/VT1.5
STM-0 AU-3, AU-3/TU-12, AU-3/TU-11
STM-1e AU-4, AU-4/TU-3, AU-4/TU-12, AU-4/TU-11, AU-3, AU-3/TU-12,
AU-3/TU-11
STM-0e AU-3, AU-3/TU-12, AU-3/TU-11
