IN1806 and IN1808 Series Scaling Presentation Switchers • Introduction 2
Models
The presentation switchers are available in the following models:
Model Description Inputs Outputs
IN1806 1U high 1 DisplayPort
5 HDMI
1 HDMI
1 DTP2/XTP/HDBT
1 HDMI Loop Out
IN1808 1U high 1 DisplayPort
5 HDMI
2 DTP2/XTP
1 HDMI
1 DTP2/XTP/HDBT
1 HDMI Loop Out
IN1808 IPCP SA Stereo amplifier
model
2U high
1 DisplayPort
5 HDMI
2 DTP2/XTP
1 HDMI
1 DTP2/XTP/HDBT
1 HDMI Loop Out
IN1808 IPCP MA 70 70 V mono
amplifier model
2U high
1 DisplayPort
5 HDMI
2 DTP2/XTP
1 HDMI
1 DTP2/XTP/HDBT
1 HDMI Loop Out
Integrated Digital Twisted Pair Extension
The DTP2/XTP inputs and DTP2/XTP/HDBT outputs are proprietary signals that are created
within any of the Extron DTP Extender systems and transmitted over a single shielded
twisted pair (STP) cable.
Depending on the range of the transmitting or receiving device, the twisted pair (TP)
inputs and outputs can each travel up to 330 feet (100 meters) without a loss of signal
integrity. They also support IR (output only) and RS-232 insertion, and dedicated universal
asynchronous receiver/transmitters (UARTs).
Shielded twisted pair cabling with solid center conductor sizes of 24 AWG or better is
recommended for optimal performance.
NOTE: Extron XTP DTP 24 shielded twisted pair cable is strongly recommended for
optimal performance.
• Input —The IN1808 Series can receive signals from a remote DTP or DTP2 transmitter
(such as the DTP T USW 333) at a conference table, lectern, or wall. It can also be
integrated into an XTP CrossPoint matrix switcher system.
• Output —The IN1806 and IN1808 Series can transmit to a DTP or DTP2, XTP, or
HDBaseT receiver or directly to an HDBaseT enabled display device. It can also be
integrated into an XTP CrossPoint matrix switcher system.
• Power over DTP —The IN1806 and IN1808 Series can send power to selected DTP
or DTP2 endpoints over the same shielded CATx cable, streamlining system design and
installation.
DTP transmitters and receivers are available in compact, low-profile enclosures, and in
decorator-style wallplate and floorbox versions to suit the installation requirements of a
specific application.
