IN1806 and IN1808 Series Scaling Presentation Switchers • Operation 44
• DHCP Mode — When this mode is enabled (On), the unit obtains an IP address and
other network settings from the DHCP server. The default is Off.
To enable or disable DHCP mode:
1. Select DHCP Mode from the Communications submenu and press Enter.
2. Press the
>
and
<
button to select On or Off and press Enter again.
You can also set the DHCP mode via an SIS commands (see the DHCP mode
commands on page 82), the PCS software, or the internal web page (see Network
Settings Panel on page 109).
• IP Address — Press the  and u buttons to select an octet of the IP address.
Press the
>
and
<
buttons to adjust the value of the selected octet. The default is
192.168.254.254.
• Subnet Mask — Press the  and u buttons to select an octet of the subnet mask
address. Press the
>
and
<
buttons to adjust the value of the selected octet. The
default is 255.255.255.0.
• Gateway — Press the  and u buttons to select an octet of the gateway address.
Press the
>
and
<
buttons to adjust the value of the selected octet. The default is
0.0.0.0.
Front Panel Lockout (Executive Modes)
The IN1806 and IN1808 Series scalers have five modes of front panel security lock that limit
the operation of the device from the front panel. When the front panel controls are locked,
RS-232, USB, and Ethernet control remain operational.
NOTE: All lock modes persist after a power cycle.
The front panel lock mode can also be selected using SIS commands (see the Front Panel
Lock (Executive Mode) commands on page 77) and PCS (see the IN1806 and IN1808
Series PCS Help file).
The following table shows the functionality that is in place for each mode:
Lock Mode Input Switching Logos Volume Adjustment
0 Unlocked Unlocked Unlocked
1 Locked Locked Locked
2 Unlocked Unlocked Unlocked
3 Unlocked Unlocked Locked
4 Locked Locked Unlocked
• Mode 0 — Unlocks front panel functions. This is the default setting.
• Mode 1 — Locks all front panel functions. Pressing the Menu button in this mode
causes the message Executive Mode 1 Enabled to appear on the display. This mode
can be enabled or disabled only via SIS commands and PCS.
• Mode 2 — Locks all front panel functions except input switching, logos, and volume
control. Pressing the Menu button in this mode causes the message Executive Mode 2
Enabled to appear on the display. To enable lock mode 2, press and hold the Menu and
Enter buttons simultaneously for 2 seconds.
• Mode 3 — Locks all front panel functions except input switching and logos.
• Mode 4 — Locks all front panel functions except volume control.
