Symbol Definitions
NOTES:
• Upper- and lowercase text can be used interchangeably unless otherwise stated.
• If the unit does not support or recognize an entered command, it ignores the command and
nothing happens.
•
= Space
]
= Carriage return with line feed
}
= Carriage return with no line feed
|
=
Pipe (can be used interchangeably with the } character)
E
= Escape
W
=
Can be used interchangeably with the E character
X!
= Input selection Response is two digits, padded with a zero.
1 = DisplayPort input 1 (all models)
2-6 = HDMI or DVI inputs 2 through 6 (all models)
7-8 = DTP2/XTP inputs 7 and 8 (IN1808 Series only)
9 = Aux audio input
X@
= Output connector selection
1 = HDMI/DVI output 1A
2 = DTP2/XTP/HDBT output 1B
3 = HDMI/DVI Loop output
X#
= Digital video format
0 = No signal
1 = DVI
2 = HDMI
3 = DisplayPort
X$
= Audio input
1 = DP 1
2 = HDMI 2
3 = HDMI 3
4 = HDMI 4
5 = HDMI 5
6 = HDMI 6
7 = TP 7 (IN1808 Series only)
8 = TP 8 (IN1808 Series only)
9 = Aux In
10 = Mic/Line 1
11 = Mic/Line 2
12 = Line In 3
13 = Line In 4
14 = File Playback L
15 = File Playback R
X%
= Audio output connector
selection
1 = HDMI 1
2 = TP 2
3 = Over DTP Analog
4 = Line Out 1
5 = Line Out 2
6 = Line Out 3
7 = Line Out 4
X^
= Total lines Response is four digits, padded with zeros.
X&
= Total pixels Response is four digits, padded with zeros.
X*
= Active lines Response is four digits, padded with zeros.
X(
= Active pixels Response is four digits, padded with zeros.
X1)
= Enable or disable
0 = Off or disabled
1 = On or enabled
