IN1806 and IN1808 Series Scaling Presentation Switchers • Operation 23
Operation
This section contains information on the front panel operation, on-screen display menu
system, and reset modes of the scalers. Topics in this section include:
• Front Panel Overview
• Powering Up
• Selecting an Input
• Selecting a Logo
• Using the On-Screen Menu System
• Front Panel Lockout (Executive Modes)
• Reset Modes
• RS-232 and IR Signal Insertion
Front Panel Overview
The IN1806 and IN1808 Series front panel features differ from each other as follows (see
the legend on the next page): both IN1808 IPCP models have IPCP Pro 355 Control
Processors, while IN1806 and the IN1808 base model do not. The two IPCP models have
identical front panels, except for their product names.
A
F
C
B
G
D
E
IN1806
B
EF
G
C
D
A
IN1808 Base Model
A
B
EF
H
G
C
D
IN1808 IPCP Models
Figure 14. IN1806 and IN1808 Series Front Panels
14
