Extron electronics IN1806 Series - Command and Response Tables for SIS Commands

IN1806 and IN1808 Series Scaling Presentation Switchers • SIS Configuration and Control 62
Command and Response Tables for SIS Commands
Command ASCII Command
(Host to Scaler)
Response
(Scaler to Host)
Additional Description
Input Configuration
Input Selection
Video and audio input
X!
*
X@
! In
X!
*
X@
•All
]
Select video and audio from input
X!
to
output
X@
.
Video input
X!
*
X@
% In
X!
*
X@
•Vid
]
Select video from input
X!
to output
X@
.
X@
= 1 for all models.
Audio input
X!
*
X@
$ In
X!
*
X@
•Aud
]
Select audio from input
X!
to output
X@
.
X@
= 1 for all models.
View current input
X@
!
X!]
View the input sources for output
X@
.
View video input
X@
%
X!]
View the video source for output
X@
.
View audio input
X@
$
X!]
View the audio source for output
X@
.
Input Video Format
View detected input format
X!
*\
X#]
Verbose modes 2 and 3:
Vtyp
X!
*
X#]
View video format
X#
detected on input
X!
.
Video Input Name
Write input name
E
I
X!
*
X1$
VNAM
}
VnamI
X!
*
X1$]
Set name
X1$
for video input
X!
.
View input name
E
I
X!
VNAM
} X1$]
View name
X1$
of video input
X!
.
NOTE: To clear an input name, enter a single space for
X1$
. The input name is reset to the default.
KEY:
X!
= Input selection
1 = DisplayPort input 1
2-6 = HDMI or DVI input 2, 3, 4, 5, or 6
7-8 = DTP2/XTP input 7 or 8 (IN1808 Series only)
9 = Aux audio input
X@
= Output
1 = HDMI/DVI output 1A
2 = DTP2/XTP/HDBT output 1B
3 = HDMI/DVI Loop output
X#
= Input digital video format (view only)
0 = No input signal detected
1 = DVI
2 = HDMI
3 = DisplayPort
X1$
= Input name (text label) Can contain up to 32 characters, excluding: , (comma) ,*, and
|
.
Default = Video•Input•
X!
.
