IN1806 and IN1808 Series Scaling Presentation Switchers • SIS Configuration and Control 65
Command ASCII Command
(Host to Scaler)
Response
(Scaler to Host)
Additional Description
Input Configuration (continued)
Auto-input Switch Mode
Set the auto-input switch
mode
EX3)
AUSW
}
Ausw
X3)]
Set the auto-input switch mode to
X3)
.
View auto-input switch
mode
E
AUSW
} X3)]
View current auto-input switch mode
X3)
.
Set user priority order
E
P
X3!
•
X3!
•...•
X3!
AUSW
}
AuswP
X3!
•
X3!
•...•
X3!]
Set the input priority switching order,
highest priority (first) to lowest (last).
NOTE: The Set Priority command returns an E13 error code unless the correct number of
X3!
variables are entered.
View priority order
E
P AUSW
} X3!
•
X3!
•...•
X3!]
View the order in which the inputs will
be selected (highest to lowest priority).
View memory priority
E
O AUSW
} X3!
•
X3!
•...•
X3!]
View the auto-input switch priority order
(highest to lowest) stored in memory.
Set timeout
E
T
X3@
AUSW
}
AuswT
X3@]
Set the amount of time without video to
switch to the previous input.
View timeout
E
TAUSW
} X3@]
View the auto-input switch timeout
duration in seconds.
KEY:
X3)
= Auto-input switch mode
0 = Disabled — Manual switching (default)
1 = User-defined priority mode —
The scaler selects the
input to which the user assigns priority. If no priority is
assigned, the scaler selects the active input with the
highest number.
2 = Last connected mode —
The scaler selects the
most recently applied input, and retains a history of the
order in which active inputs are connected to the unit. If an
active input is removed, the scaler switches to the most
recently prioritized input.
X3!
= Input number for setting user priority
Arrange input numbers in user priority order.
1 = Input 1, 2 = input 2, 3 = input 3, 4 = input 4, 5 = input 5,
6 = input 6.
7 = Input 7, 8 = input 8 (IN1808 Series only)
X3@
= Auto-input switch timeout
Number of seconds without video that elapse before switching
to the input with the next priority.
1 through 500 (in 1-second increments, default = 3 seconds)
0 = Immediately switch to the input with the next priority if the
current input is removed.
Picture Adjustments
Freeze
Enable
1*1F
Frz1*1
]
Freeze the output on the screen.
Disable
1*0F
Frz1*0
]
Unfreeze the output.
View
1F
X1)]
Show the freeze status of the output.
KEY:
X1)
= On or Off status
0 = Off or disabled (default)
1 = On or enabled
