IN1806 and IN1808 Series Scaling Presentation Switchers • SIS Configuration and Control 66
Command ASCII Command
(Host to Scaler)
Response
(Scaler to Host)
Additional Description
Picture Adjustments (continued)
Contrast
Set a specific value
EX!
*
X1%
CONT
}
Cont
X!
*
X1%]
Set the range of image light and dark
values (contrast level) to
X1%
for input
X!
.
Increment contrast value
EX!
+ CONT
}
Cont
X!
*
X1%]
Increment contrast level
X1%
for input
X!
.
Decrement value
EX!
– CONT
}
Cont
X!
*
X1%]
Decrement contrast level
X1%
for input
X!
.
View contrast
EX!
CONT
} X1%]
View the current contrast level for input
X!
.
Brightness
Set a specific value
EX!
*
X1%
BRIT
}
Brit
X!
*
X1%]
Set the intensity of video light on the
screen (brightness level) to
X1%
for input
X!
.
Increment value
EX!
+ BRIT
}
Brit
X!
*
X1%]
Increment brightness level
X1%
for input
X!
.
Decrement value
EX!
– BRIT
}
Brit
X!
*
X1%]
Decrement brightness level
X1%
for input
X!
.
View
EX!
BRIT
} X1%]
View the current brightness level for
input
X!
.
Detail Filter
Set detail level
E
1*
X1%
HDET
}
Hdet1*
X1%]
Specify the detail (sharpness) level to
X1%
.
Increment value
E
1 + HDET
}
Hdet1*
X1%]
Increment the detail level.
Decrement
E
1 + HDET
}
Hdet1*
X1%]
Decrement the detail level.
View
E
1HDET
} X1%]
View the current detail setting (
X1%
) for
the currently selected input.
Horizontal Position (Shift) — Image
Specific value
E
I1*
X1^
HCTR
}
HctrI1*
X1^]
Set the horizontal position of the image
in relation to the top left corner of the
output raster to
X1^
.
Increment value
E
I1+HCTR
}
HctrI1*
X1^]
Shift the image right 1 pixel.
Decrement value
E
I1–HCTR
}
HctrI1*
X1^]
Shift the image left 1 pixel.
View
E
I1HCTR
} X1^]
View image horizontal centering value
X1^
.
KEY:
X!
= Input selection
1 = DisplayPort input 1
2-6 = HDMI or DVI input 2, 3, 4, 5, or 6
7-8 = DTP2/XTP input 7 or 8 (IN1808 Series only)
9 = Aux audio input
X1%
= Picture adjustment
0-127 (default = 64)
X1^
= Horizontal and vertical position (shift)
The position is ± the horizontal or vertical position of the
highest output resolution. The response is five digits,
padded with zeros and preceded by + or –.
