IN1806 and IN1808 Series Scaling Presentation Switchers • SIS Configuration and Control 67
Command ASCII Command
(Host to Scaler)
Response
(Scaler to Host)
Additional Description
Picture Adjustments (continued)
Vertical Position (Shift) — Image
Specific value
E
I1*
X1^
VCTR
}
VctrI1*
X1^]
Set the vertical position of the image
in relation to the top left corner of the
output raster to
X1^
.
Increment value
E
I1+VCTR
}
VctrI1*
X1^]
Shift the image down by 1 line.
Decrement value
E
I1–VCTR
}
VctrI1*
X1^]
Shift the image up by 1 line.
View
E
I1VCTR
} X1^]
View image vertical centering value
X1^
.
Horizontal Size — Image
Specific value
E
I1*
X1&
HSIZ
}
HsizI1*
X1&]
Set the horizontal size (width) of the
image to
X1&
.
Increase horizontal size
E
I1+HSIZ
}
HsizI1*
X1&]
Widen the image by 1 pixel.
Decrease horizontal size
E
I1–HSIZ
}
HsizI1*
X1&]
Narrow the image by 1 pixel.
View
E
I1HSIZ
} X1&]
View image horizontal size
X1&
.
Vertical Size — Image
Specific value
E
I1*
X1&
VSIZ
}
VsizI1*
X1&]
Set the vertical size (height) of the image
to
X1&
.
Increase vertical size
E
I1+VSIZ
}
VsizI1*
X1&]
Make the image taller by 1 line.
Decrease vertical size
E
I1–V SIZ
}
VsizI1*
X1&]
Shorten the image by 1 line.
View
E
I1VSIZ
} X1&]
View image vertical size
X1&
.
Compound Image Position and Size — Image
Specific value
E
1,
X1^
*
X1^
*
X1&
*
X1&
XIMG
}
Ximg1,
X1^
*
X1^
*
X1&
*
X1&]
Set the horizontal (x) and vertical (y)
position (
X1^
) and horizontal and vertical
size (
X1&
) for the image.
View
E
1XIMG
} X1^
*
X1^
*
X1&
*
X1&]
View x, y position and x, y size for
image.
KEY:
X1^
= Horizontal and vertical position (shift)
The position is ± the horizontal or vertical position of the
highest output resolution.
• The response is five digits, padded with zeros and
preceded by + or –.
• The logo vertical position allows up to ± 2400.
X1&
= Horizontal and vertical size
• Horizontal = 10 to two times the maximum supported
output resolution
• Vertical = 10 to two times the maximum supported
output resolution
