IN1806 and IN1808 Series Scaling Presentation Switchers • SIS Configuration and Control 68
Command ASCII Command
(Host to Scaler)
Response
(Scaler to Host)
Additional Description
Output Configuration
Output Video Mute
Unmute output video
X@
*0B Vmt
X@
*0
]
Unmute video output
X@
.
Mute output video
X@
*1B Vmt
X@
*1
]
Mute video output
X@
.
Mute video and sync
X@
*2B Vmt
X@
*2
]
Mute video and sync on output
X@
.
View mute status
X@
*B
X4@ ]
View video mute status
X4@
for output
X@
.
Video Mute — All Outputs
Mute all outputs
1B
Vmt1
]
Mute video on all outputs.
Mute sync and video
2B
Vmt2
]
Mute video and sync on all outputs.
Unmute video and sync
0B
Vmt0
]
Display all outputs.
View global mute
B
X4@
•
X4@
•
X4@]
Verbose modes 2 and 3:
Vmt
X4@
•
X4@
•
X4@]
View video mute status
X4@
of all
outputs.
NOTE: Video is unmuted (default) after a power cycle.
Output Scaler Rate
Set output rate
E
1*
X2!
RATE
}
Rate1*
X2!]
Select the output resolution and refresh
rate (
X2!
).
View output rate
E
1RATE
} X2!]
View the selected output rate.
Video Output Name
Write output name
E
O
X@
*
X1$
VNAM
}
VnamO
X@
*
X1$]
Set name
X1$
for video output
X@
.
View output name
E
O
X@
VNAM
} X1$]
View name
X1$
of video output
X@
.
NOTE: To clear an output name, enter a single space for
X1$
. The output name is reset to the default.
Loop Out Tie
Set loop out
EX!
LOUT
}
Lout
X!]
Tie the Loop output to input
X!
.
View loop out setting
E
LOUT
} X!]
View the Loop output setting.
Default = 1
KEY:
X@
= Output
1 = HDMI/DVI output 1A
2 = DTP2/XTP/HDBT output 1B
3 = HDMI/DVI Loop output
X1$
= Output name (text label) Can contain up to 32 characters, excluding , (comma) ,*, and
|
.
Default = Video•Output•
X@
.
X2!
= EDID emulation
See the Input EDID and Output Resolutions table on page 56.
X4@
= Output video mute
0 = Unmute video
1 = Mute video to black screen
2 = Mute video and sync
