IN1806 and IN1808 Series Scaling Presentation Switchers • SIS Configuration and Control 69
Command ASCII Command
(Host to Scaler)
Response
(Scaler to Host)
Additional Description
Output Configuration (continued)
HDMI Output Format
Set output format
EX@
*
X4*
VTPO
}
Vtpo
X@
*
X4*]
Set the colorspace and format for HDMI
output
X@
to
X4*
.
View format setting
EX@
VTPO
} X4*]
View the current output colorspace and
format for output
X@
.
View auto output format
EX@
*VTPO
} X4*]
View the output format when
X4*
is set
to 0 (Auto).
KEY:
X@
= Output
1 = HDMI/DVI output 1A
2 = DTP2/XTP/HDBT output 1B
3 = HDMI/DVI Loop output
X4*
= HDMI output format and colorspace
0 = Auto — HDMI RGB Full to a CEA sink, or DVI to a non-CEA sink
1* = DVI — RGB 444, 0-255. Valid for output rates up to 165 MHz
2 = HDMI RGB Full — RGB 444, 0-255
3 = HDMI RGB Limited — RGB 444, 16-235
5 = HDMI YUV 444 Limited — YUV 444, 16-235
7 = HDMI YUV 422 Limited — YUV 422, 16-235
* If the scaler is in DVI mode and a rate greater than 165 MHz is selected,
the HDMI output defaults to HDMI RGB 444 Full.
Power Save
Set power save mode
EX6@
PSAV
}
Psav
X6@]
Set the power save mode to
X6@
.
View power save mode
E
PSAV
} X6@]
View the current power save mode.
KEY:
X6@
= Power save mode
0 = Full power mode (default)
1 = Lowest power state — TP remote power and over TP functions
are disabled.
2 = Low power state — Over TP and TP remote power are enabled.
