IN1806 and IN1808 Series Scaling Presentation Switchers • Internal Web Pages 102
Internal Web Page
The IN1806 and IN1808 Series scalers feature an internal web server, displayed as a web
page. This page allows you to monitor and adjust certain settings of the IN1806 and IN1808
Series via a LAN or WAN connection. Use a web browser to view the pages on a PC
connected to the scaler LAN port.
NOTE: The scaler internal web page does not support compatibility mode in Microsoft
®
Internet Explorer
®
(see Disabling Compatibility Mode on the next page). Extron
recommends using Mozilla
®
Firefox
®
or Google Chrome™.
This section gives an overview of the internal web page, which is always available and
cannot be erased or overwritten. Topics in this section include:
• Accessing the Web Page
• Web Page Components
Accessing the Web Page
1. Connect the scaler to a LAN or WAN using the rear panel RJ-45 LAN connector (see
figures 3 and 4,
K
, or figures 5 and 6,
Q
, [IN1808 IPCP SA and IN1808 IPCP MA 70
within the IPCP module], on pages 12 and 13).
2. Open a web browser on a connected PC.
3. Enter the IP address of the device in the browser Address field.
NOTE: The default IP address is 192.168.254.254.
4. Press the <Enter> key on the keyboard. The scaler checks if it is password-protected.
• If the device is not password-protected, the web page opens. Skip steps 5 through
7.
• If the device is password-protected, the Sign in window opens (see figure 46).
Proceed to step 5.
5. In the Username field, enter admin or user (optional).
Figure 46. Example of a Network Password Dialog Box
46
