Extron electronics IN1806 Series - Audio Group Master SIS Commands

IN1806 and IN1808 Series Scaling Presentation Switchers • SIS Configuration and Control 85
Audio Group Master SIS Commands
Group master symbol definitions
•
= Space
]
= Carriage return with line feed
}
= Carriage return with no line feed
|
=
Pipe (can be used interchangeably with the } character)
E
= Escape
W
=
Can be used interchangeably with the E character
X10)
= Object Identification number (OID)
Input Path OIDs:
Line Input Gain Control
(2 per channel)
OIDs Line Input Gain Control
(continued)
OID
Line Input 1 - DisplayPort
30000
30001
Line input 6 - HDMI L
30010
Line input 2 - HDMI L
30002
Line input 6 - HDMI R
30011
Line input 2 - HDMI R
30003
Line input 7 - DTP2/XTP L
30012
Line input 3 - HDMI L
30004
Line input 7 - DTP2/XTP R
30013
Line input 3 - HDMI R
30005
Line input 8 - DTP2/XTP L
30014
Line input 4 - HDMI L
30006
Line input 8 - DTP2/XTP R
30015
Line input 4 - HDMI R
30007
Aux line input L
30016
Line input 5 - HDMI L
30008
Aux line input R
30017
Line input 5 - HDMI R
30009
Mic/Line/File Player Input
Gain
OID
Mic/Line Input 1
40000
Mic/Line Input 2
40001
Line Input 3
40002
Line Input 4
40003
File player L
40004
File player R
40005
Output Attenuation
(2 per channel)
OID
Output Attenuation
(continued)
OID
HDMI L
60000
Line Output 1
60006
HDMI R
60001
Line Output 2
60007
DTP2/XTP/HDBT L
60002
Line Output 3
60008
DTP2/XTP/HDBT R
60003
Line Output 4
60009
DTP Analog L
60004
Amp L or Mono
60010
DTP Analog R
60005
Amp R
60011
