IN1806 and IN1808 Series Scaling Presentation Switchers • SIS Configuration and Control 86
X10!
= Group master number
1 through 10
Preconfigured group. Can alternatively be an alias, which
is the user-defined group name enclosed in braces ({ }).
X10#
= Soft limit high value (in dB) For gain value with a resolution to 0.1, multiply by 10.
The valid range of
X10#
must be within the range of
X10%
to set an upper limit of gain group master
X10!
.
X10$
= Soft limit low value (in dB) For gain value with a resolution to 0.1, multiply by 10.
The valid range of
X10$
must be within the range of
X10%
to set an upper limit of a gain group master
X10!
.
X10%
= Group master value For gain value with a resolution to 0.1, multiply by 10. For
mute values, use 0 or 1 as the value.
X10^
= Increment or decrement value For gain value with a resolution to 0.1, multiply by 10. For
mute values, use 0 or 1 as the value.
X10&
= Group master mute status
0 = unmuted, 1 = muted
