IN1806 and IN1808 Series Scaling Presentation Switchers • Internal Web Pages 110
2. Edit the network settings as desired:
• DHCP — Click the DHCP button (see figure 55,
1
) to toggle DHCP on and off.
When DHCP is enabled (On), the unit configures its IP address and other network
settings from the DHCP server. The default is Off.
• IP Address, (
2
), Subnet mask (
3
), and Gateway address (
4
) — To set any
of these addresses, click in the desired field and enter the address.
3. When finished editing, click Save to confirm your changes or Cancel to close the
window without making changes. You can also close the window by clicking the X in the
upper-right corner of the screen.
NOTE: If DHCP is being enabled, the web page attempts to redirect and connect to the
unit via the unit name (TCP/IP hostname). If a static IP address is being set, the web
page attempts to connect to the new IP address.
RS-232 Panel
The view-only RS-232 panel (see figure 47,
8
, on page 103) displays the RS-232 protocol
for the IN1806 and IN1808 Series serial port. The defaults are:
• Baud rate — 9600
• Parity Bit — N (none)
• Data bits — 8
• Stop bits — 1
