IN1806 and IN1808 Series Scaling Presentation Switchers • SIS Configuration and Control 56
X2!
= EDID emulation or output rate
(See the Input EDID and Output
Resolutions table.
0 = Automatic (default input EDID, matches the current
output resolution)
1 = Output 1A HDMI (available for EDID export only)
2 = Output 1B TP (available for EDID export only)
3 = Loop output (available for EDID export only)
201 – 210 = Custom EDID or output rates 1 – 10.
Input EDID and Output Resolutions
Resolution 23.98 Hz 24 Hz 25 Hz 29.97 Hz 30 Hz 50 Hz 59.94 Hz 60 Hz
Automatic*
0* — Match current scaler output resolution
640x480
10
800x600
11
1024x768
12
1280x768
13
1280x800
14
1280x1024
15
1360x768
16
1366x768
17
1440x900
18
1400x1050
19
1600x900
20
1680x1050
21
1600x1200
22
1920x1200
23
480p
24 25
576p
26
720p
29 30 31 32 33 34
1080i
35 36 37
1080p
38 39 40 41 42 43 44 45**
2048x1080 (2K)
46 47 48 49 50 51 52 53
2048x1200
54
2048x1536
55
2560x1080
56
2560x1440
57
2560x1600
58
3840x2160
59 60 61 62 63 64*** 65*** 66***
4096x2160*****
69 70 71 73 73 74**** 75**** 76****
*Default input EDID
**Default output resolution
***4:4:4 color sampling at these rates is available only when operating with an HDMI output or a DTP2
endpoint.
****4:4:4 color sampling at these rates is available only with HDMI outputs.
*****4096x2160 rates are available only for output resolution and cannot be selected for input EDID.
