IN1806 and IN1808 Series Scaling Presentation Switchers • SIS Configuration and Control 57
X2@
= Test patterns
0 = Off (default)
1 = Crop
2 = Alternating pixels
3 = Crosshatch
4 = Color Bars
5 = Grayscale
6 = Audio test — Crop pattern with orbiting text AUDIO
TEST and outputting pink noise at LPCM-2Ch,
48 kHz, 24-bit.
Response is two digits, padded with a zero.
X2^
= Input presets
1 through 128
Response is three digits, padded with zeros.
X2*
= Output sync or OSD menu
timeout
Number of seconds before output sync or the OSD menu
times out.
1 through 500 seconds, in 1-second increments
0 = Output sync is instantly disabled with no active video
from the selected input (SSAV command only).
60 = Default for the MDUR command.
501 = Output sync never times out (default for SSAV
command).
X2(
= Front Panel Lockout (executive)
mode status
0 = Off or disabled (front panel controls fully accessible)
(default).
1 = Mode 1 — Complete front panel lockout
2 = Mode 2 — Input switching, logos, and audio
adjustments only
3 = Mode 3 — Input switching and logos only
4 = Mode 4 — Volume adjustments only
X3)
= Auto-input switch mode
0 =
Disabled — Manual switching (default)
1 = User-defined priority mode —
The scaler selects the
input to which the user assigns priority. If no priority
is assigned, the scaler selects the active input with the
highest number.
2 =
Last connected mode —
The scaler selects the most
recently applied input, and retains a history of the
order in which active inputs are connected to the unit.
If an active input is removed, the scaler switches to
the most recently prioritized input.
X3!
= Auto-input switching priority
Input number for input switching priority.
1 = Input 1
2 = Input 2
3 = Input 3
4 = Input 4
5 = Input 5
6 = Input 6
7 = Input 7 (IN1808 Series only)
8 = Input 8 (IN1808 Series only)
X3@
= Auto-input switch timeout Number of seconds without video that elapse before
switching to the previous input.
1 through 500 in 1-second increments
3 = default (3 seconds)
0 =
Immediately switch to most recent input if the
current input is removed.
