IN1806 and IN1808 Series Scaling Presentation Switchers • SIS Configuration and Control 55
X1@
= Internal temperature In degrees Celsius. Response is two digits, padded with
a zero.
X1#
= Horizontal and vertical
frequencies
nnn.nn Response is three digits with two decimal
places, padded with zeros. (Example: 075.32)
X1$
= Text label
Up to 32 characters. Cannot contain , (comma) ,*, or
|
.
NOTES:
• Input presets saved without a name are given the default name INPUT PRESET nnn. The
default logo name is Logo nn (for example, Logo 05)
• Saving a file name consisting of a single space repopulates the field with the default name.
X1%
= Picture adjustment
0-127 (default = 64)
Response is three digits, padded with zeros.
X1^
= Horizontal and vertical position
(shift)
Range is ± the horizontal or vertical position of the
maximum supported output resolution.
• Response is five digits, padded with zeros and
preceded by + or –.
• The logo vertical position allows up to ± 2400.
X1&
= Horizontal and vertical size
Horizontal = 10 to two times the maximum supported
output resolution
Vertical = 10 to two times the maximum supported
output resolution
Response is five digits, padded with zeros.
X2)
= EDID file 128 or 256 bytes of binary data
